Rotary Kiln

Ceramsite Rotary kiln

    Ceramisite sand rotary kiln is a used to produce calcined ceramiste products by roasting and calcining granule ceramiste materials. Diameter ranges from 1.2m to 3.8m. Featured in large unit volume, long service life, high running rate, stable operation, good heat transfer efficiency and low heat consumption, Taeda ceramisite sand rotary kiln is regarded as an ideal ceramiste calcining equipment. Besides plastic method, mud balling, powder balling and crushing method production line, it is also suitable for producing ceramiste by calcining sludge.

    Application:Suitable for ceramsite sand, sludge, clay, kaolin, fly ash, shale and etc.

    物料

  • Order online Hotline:18939509384
Advantage:

Reduce Cold Air Entrance and Dust Leak

Junction between kiln head rotary drum and fixed kiln head and junction between kiln tail rotary drum and fixed flue gas chamber are well sealed, which can prevent outside air from being inhaled and stabilize thermal process in kiln. Meanwhile, good seal performance can prevent dust leak under abnormal operation.


Suitable For Petroleum Ceramsite and Construction Ceramsite

Taeda ceramsite sand rotary kiln is key equipment for ceramsite production line. Besides shale and fly ash ceramsite, it is widely used in calcining and producing ceramsite from sludge, clay, yellow mud, river bottom silt, fly ash, shale, slag, coal gangue, polluted soil, construction waste and relevant raw materials.

Working principle:

Ceramsite sand rotary kiln is composed of rotary cylinder, supporting device, supporting device with blocking wheel, kiln head, kiln tail sealing device and a coal injection pipe device. Kiln body has a certain inclination with the horizontal level. Whole kiln body is supported by supporting roller device and there is a blocking wheel device to control up and down movement of kiln body.

In addition to main drive, transmission part is also provided with an auxiliary drive to ensure that kiln body can still rotate at a slow speed and prevent the kiln body from being deformed when main drive power supply is interrupted. Kiln head adopts shell-type seal, and the kiln tail is equipped with an axial contact sealing device to ensure the reliability of the seal.

Delivery display:
 回转窑发货现场    回转窑发货现场    回转窑发货现场    回转窑发货现场
Project case:
  • 回转窑生产现场

    Jinan Lime Kiln Production Line

    Attracted by lime rotary kiln manufactured by Zhengzhou Taida, Jinan customer purchased a whole set of lime rotary kiln calcining machine to fulfill final production aim.

    Raw material: Lime
    Output capacity:350t/d

  • 回转窑生产现场

    10TPH Russia Gypsum Production Site

    Gypsum for is with high moisture. For guaranteeing smooth feeding, there is a certain inclination of feeding end for gypsum kiln. Whole line contains burner, rotary kiln and exhaust disposal.

    Raw material:Phosphaste gypsum
    Output capacity:1-10T/H

Working parameter:
ModelCapacity(t/h)Support deviceGearboxMotor modleInstalled power (kW)
Ø2.2×45m 3.5 3 Group ZS125-5 YVF2-225M-4 45
Ø2.5×50m 5 3 Group ZS145-5 YVF2-250M-4 55
Ø2.8×50m 8.5 3 Group ZS165-6 YVF2-280S-4 75
Ø3.0×55m 11 3 Group ZS165-3 YVF2-280M-4 90
Ø3.2×60m 15 3 Group ZL130-16 YVF2-315L2-6 132
Ø3.6×64m 20 3 Group ZSY560-63 YVF2-355M1-6 160
Ø3.8×70m 26 3 Group ZSY560-63 YVF2-355M4-6 200
Applicable material:
